Published: 2009-08-18,
Last Updated: 2009-08-19 00:26:36 UTC
by Daniel Wesemann (Version: 1)
comment(s)
If you are, as I am, a GCFA who attended Rob Lee's famous training in
the not-so-recent past, you probably still are "carving out" partitions
from within an acquired full disk "dd" image by running it through
another "dd". Given how quickly the disk sizes are increasing, this is
highly inefficient both in terms of disk space and analyst time used.
But there's a better way. You already know how to use "loopback
mount" on Linux to mount an image? Well, loopback mount supports an
"offset" parameter that lets you mount a partition directly from within a
larger full-disk image. Thusly:
root@ubuntu:/media/disk-1# ls -al
total 39082701
drwxrwxrwx 1 root root 4096 2009-07-12 13:33 .
drwxr-xr-x 4 root root 4096 2009-08-18 19:04 ..
-rwxrwxrwx 1 root root 878 2009-07-07 11:46 fdisk
-rwxrwxrwx 1 root root 701 2009-07-07 11:47 hdparm
-rwxrwxrwx 2 root root 40020664320 2009-07-07 14:34 image-sda
-rwxrwxrwx 1 root root 43 2009-07-07 12:02 md5sum
-rwxrwxrwx 1 root root 43 2009-06-29 13:13 md5sum-sda
drwxrwxrwx 1 root root 0 2009-07-11 19:03 $RECYCLE.BIN
root@ubuntu:/media/disk-1# fdisk -ul image-sda
You must set cylinders.
You can do this from the extra functions menu.
Disk image-sda: 0 MB, 0 bytes
255 heads, 63 sectors/track, 0 cylinders, total 0 sectors
Units = sectors of 1 * 512 = 512 bytes
Disk identifier: 0x9c879c87
Device Boot Start End Blocks Id System
image-sda1 * 63 78140159 39070048+ 7 HPFS/NTFS
Partition 1 has different physical/logical endings:
phys=(1023, 254, 63) logical=(4863, 254, 63)
root@ubuntu:/media/disk-1# mount -o ro,loop,offset=32256 -t auto image-sda /media/image
root@ubuntu:/media/disk-1# cd ..
root@ubuntu:/media# cd image
root@ubuntu:/media/image# ls
AUTOEXEC.BAT favorites ntldr Start Menu blp
INFCACHE.1 pagefile.sys System Volume Information
boot.ini IO.SYS Program Files temp
CONFIG.SYS MSDOS.SYS RECYCLER WINDOWS Documents and Settings NTDETECT.COM spoolerlogs
root@ubuntu:/media/image#
The magic "
32256" offset passed to "mount" is easily explained as the start of the partition you are interested in (
63 in this case) multiplied by the unit size (
512 in this case). If you have more than one partition, just repeat the above steps for the other slices.
There you go. This easily saves several hours and untold gigabytes of disk space compared to the GCFA "carving out" method.
taken from: https://isc.sans.edu/diary.html?storyid=6991
